Multi Spring Heavy Duty Seal - 26 M/s Velocity, 35 Bar Pressure | Balanced Design, Uniform Face Loading, Externally Mounted

Our multi spring heavy duty has the velocity of 26 m/s, axial movement of - 0.5 mm and pressure of 35 bar. This inside mounted/externally mounted and double action product has shaft diameter range of 18 to 160 mm and temperature range of (-)45 to 260 deg. C. Salient features of the product include:


* Balanced
* Uniform face loading
* Multiple spring design


This special design exercises even pressure on the face. The product includes a balanced primary ring that makes it ideal for high level of pressures. Instead of secondary seal ring, PTFE, Nylon & Graphoil wedge are also available with us. These are identified as MS 510BW. Main application areas include:


* Chemical pumps for fertilizer
* Petrochemical industries
* Acids & corrosive chemical
* Sugar industry
* Falling film evaporator
* Hot / clear juice circulation
* Fermented / spent wash
