Multi Hole Waveguide - Aluminium Alloy, Custom Sizes, Up To 40 Ghz | Low Insertion Loss, Multiple Precision Holes, Flange Mount

Get Latest Price

Minimum Order Quantity :

5 Piece

In Stock

Product Specifications

Range	Upto 40 GHz (Depends on Size and Design)
Shelf Life	Long Operational Life
Interface Type	Rectangular Waveguide Interface
Connectivity Type	Flange or Screw Type
Features	Multiple Precise Holes for Controlled Signal Propagation, Low Insertion Loss, High Signal Integrity
Mounting Type	Panel or Rack Mountable
Size	Standard and Custom Sizes Available
Model	MHWG-Standard
Frequency	X-Band/Ku-Band/K-Band Options (Customizable)
Operating Temperature	-40C to +85C
Product Type	Multi Hole Waveguide
Application	Microwave and Radar Systems, Satellite Communication, Laboratory Experiments
Dimension (LWH)	Standard Waveguide Sizes (Customizable)
Material	High-Quality Aluminium Alloy
Weight	Approx. 500g (Varies by Size)
Capacity	High Power Handling Capability
Coverage Area	Specified by Frequency and Application
Supply Ability	100 Per Month
Delivery Time	7 Days
Main Domestic Market	All India
