Multi Function Hoist

We are Exporting, Manufacturing and Supplying a best collection of Multi Function Hoist in Kolkata. Latest in hoisting solutions by Jaypee the MFH series is a multi-functional equipment for all your hoisting needs. The hoist can be used for carrying concrete and also finishing materials such tiles, fittings etc. With an optional rebar carrying attachment, users can now eliminate the need for installation of tower cranes at site.

Technical Data

Model:MFH 100MFH 150
Loading Capacity:1000 Kgs (1 Ton)1500 Kgs (1.5 Ton)
Max Height:70 Meters120 Meters
Cage Size (L x B x H):900 - 800 - 600 mm1200 - 900 - 600 mm
Lifting Speed:30 Meters / min30 Meters / min
Travel Type:Wire RopeWire Rope
Motor Power:7.5 HP (5.5 KW)12.5 HP (9.3 KW)
Power TransmissionHeavy Duty Wire Rope WinchHeavy Duty Wire Rope Winch
Mast & Cage Finish Wall TiesShot Blasted, Zinc Chromate Primer & High Quality Enamel Paint
Self Erecting MechanismIncludedIncluded
Safety Features:Wire Rope Snapping DeviceWire Rope Snapping Device
Slack Rope Safety Device:Slack Rope Safety Device
Lower & Upper Limit Switch:Lower & Upper Limit Switch
Optional Attachment:Concrete Bucket - 0.4 cu/-1 ton.Concrete Bucket - 0.4 cu/-1 ton
Vertical Rebar Attachment upto 6 mtr. longVertical Rebar Attachment upto 6 mtr. long
Optional Features:FC DriveFC Drive
Horizontal Rebar Attachment 6 meterHorizontal Rebar Attachment 6 meter
Concrete Bucket AttachmentConcrete Bucket Attachment
