Model Sedimentation Tank - Application: Chemical Engineering Laboratory Equipments

The apparatus is designed to demonstrate the hydraulic characteristics and settling efficiencies of a model settling basin. The apparatus consists of a Sedimentation Tank in which the water is fed by overhead tank (available in user laboratory and not in scope of supply) at constant flow rate and is measured with the help of a Rotameter.
A complete unit for slurry circulation in sedimentation tank also accompanies the set-up including a sump tank for slurry, a feed pump for slurry. Flow rate of slurry entering the sedimentation tank is metered by suitable device.
An accurate dye injection system is provided to inject the known volume of dye in the sedimentation tank. In sedimentation tank a weir is fitted which facilitate to the entry of well mixed slurry of known concentration in sedimentation tank uniformly.
Product Specification
Material: pvc/ss
Type of Service Contract: Project Based
Dimension: 6X4X5 FEET
Usage/Application: LAB EXPERIMENT
Current: 220V
Cylinder: NA
