Mini Starlit Lux Camera

Following are the technical specifications of Mini starlit Lux Camera :

Technical Specification :
Model : AD-120BHEXP4
Image Device : 1/3 Sony B/W CCD
Minimum Illumination : 0.0003 Lux
Number of Pixels : CCIR:(H)752x(V)582 / EIA:(H)762x(V)492
Scanning System : PAL / NTSC
Sync System : Internal Synchronization
Horizontal Resolution : 600TV Lines
Video Output : 1Vp-p 75IC Negative
White Balance, AGC, BLC Auto
S/N Ratio : More than 48dB
Gamma Characteristic : 0.45
Electronic Shutter : PAL:1/50~1/100,000s ; NTSC:1/60~1/100,000s
Power Consumption : 12V+_10%DC,100mA
Operation Temperature : -10A C~+50A C
Storage Temperature : -20A C~+60A C
Built-In Lens : f: 3.7mm pinhole lens
Dimension : 20x20mm

Accessories Furnished:

*DIY cable with BNC/RCA for Video,DC-Jack for Power;
*U type bracket;
*Manual.

Application: indoor
Connection: refer to FAQ
