Mini Robot - 5-axis Articulated Arm, 250g Payload Capacity | Precision Movement With 1mm Resolution, High-speed Operations

Mini Robot

We offer wide range of mini robot.
Performance Features:- Payload : 250 gms Resolution : 1mm Weight of
Robot : 7-8 Kg max Repeatability : 1mm Joint:- Waist : 300 degree
Shoulder : 90 degree Elbow : 90 degree Pitch : 180 degree Roll : 200
degree Mechanical:- Configuration : MINI ROBOT No. of Axes : 5 (3 axes
waist shoulder- elbow manipulator with 2 axes pitch-roll) Link 1 : 120
mm Link 2 : 100 mm Vertical Height : 250 mm Joint Actuators : Stepper
motors Transmission : Gear train ,Joint 1 ,2 & 3 : Ball bearing
Position Feedback : Open loop Gripper : Parallel jaws type Gripper
Actuator : Geared DC motor Gripper Transmission : Spur Gear mechanism
Speed:- Waist : 90 degrees/s Shoulder : 60 degrees/s Elbow : 60
degrees/s Pitch : 90 degrees/s Roll : 90 degrees/s.

For more details contact us.
