Microprocessor Controlled Quill Feed

Being a customer-focused organization, we are indulged in providing a premium quality collection of Microprocessor Controlled Quill Feed to the clients from Delhi. The Model 708 Microprocessor Controlled Quill Feed is factory installed (or factory retrofitted) on any Servo drill press for peck drilling and reaming cycles, or routine drilling of deep holes. Fully automates hole drilling. All 708 units now feature a built-in battery backup with approximately 35 hours of backup time. This eliminates the need to re-program in the event of a power failure. All previously manufactured 708 units can be upgraded with the battery backup. Please call for information.

Program and run all operations from the controller keyboard
Programmable dwell, chip clearing height and variable peck depth
Peck Steps: 0.001-1.4 / 0.02mm-35.6mm
Hole depth accuracy: +0.001 / 0.02mm
Quill Travel: 1.4 / 35.6mm
Maximum quill force: 35 Lbs. / 16 Kg
Feed rates: 0.01-30 IPM / 0.250750mm/min
Battery Backup - retains controller program for approx. 35 hours
Optional Extended Battery Backup - approx. 72 hours backup time
Optional foot switch (Model 710)
