Micro Card Reader

Our organization is engrossed in manufacturing and supplying of Radiation Monitor in Mumbai, Maharashtra, India. Tag Reader is a RFID reader with LED indicators and RS485 interface. It uses the trusted, Secure Mifare technology to authenticate card holder.

Mifare (ISO-14443-A) standard card Read facility.
Provides 30-90 mm Card sensing range. Depends on the TAG size.
Audio Indication: Melodies for different card events.
Visual Indication: Two colour LEDs for indicating status.
Built-in RS-485 interface.
Card reading & processing time < 100ms.
Wide operating Power supply: 8 to 24V dc.
Enclosure: ABS Grey colour, Weight 400 gms
Size: 92 x 62 x 30 mm.
Ingress Protection: IP-65.
Wall mounting.
Arrangement for easy installation / maintenance
Input Protection: over-voltage, reverse polarity and over current.
Operating Temperature: 0-50 Deg. C, Humidity: 0-95% RH (Non-condensing)
Optional: ISO14443-B or ISO15693 card Read/Write.
Easy facility for daisy chaining, multiple Readers.
Easy to install using quick detachable connector, cable shares power and
data signal.
Current consumption: 30 mA at 24V.
Facility to assign unit ID for multi-drop communication.
Implements MODBUS-RTU protocol for communication.
