Mechanically Actuated Diaphragm Pump - Composite Ptfe Hypalon Diaphragm, Aluminum Body For Lightweight Durability, Adjustable Manual Flow Control

As we are considered a well-known company, we are involved in manufacturing, distributing and trading a wide range of Mechanically Actuated Diaphragm Pump to meet the demands of our customers. Our products have been designed to give optimum performance and are available in customized specification. Mechanically Actuated Diaphragm Pump is also used as air compressor as well as source for low-grade vacuum.

Specification:
* Mechanically actuated diaphragm
* High Precision balls and seal rings for accuracy
* Manual flow control, adjustable while running through stroke length adjustment knob
* Composite PTFE Hypalon diaphragm for long life
* Motor driven worm shaft & worm wheel drive
* Light weight aluminum alloy body, Liquid end material of construction
* Turn down Ration 10:1
* Steady state accuracy: +/- 3%, Repeatability: +/- 3%

Housing : Aluminum
Suction/Discharge Fittings : PVC
Spacer : Cast Iron
Pressure Relief Valve : PVC
Base Frame : MS
Injection Check Valve : PVC
Head : Polypropylene (PP)
Y Strainer (or) Foot valve : PVC
Diaphragm : PTFE faced hypalon
Tubing : LDPE
Ball : PTFE
Ring seal : PTFE
