Manual Valves - Astm A216 Gr Wcb, Aisi Type 304/316 Stem, 1/2" To 6" Size | Bi-directional Shut Off, Easy Maintenance With Top Entry Design, Replaceable Seats, Low Pressure Sealing, Multiple Soft Seat Options Available
Price:
Get Latest Price
In Stock
Product Specifications
| Body Material | ASTM A216 GR WCB |
| Stem Material | AISI 304, 316 |
| Seat Material | PTFE |
| Gland Packing | PTFE |
| Gasket Material | PTFE |
| Design Standard | BS 5156 |
| Testing Standard | BS 6755-1 /API 598 |
| Features | Easy maintenance, Replaceable seats, Low pressure seal, Bi-directional shut, Compensates wear, Soft seats avail, Stainless steel |
Product Overview
Key Features
Specification-
Body/Bonnet/Plug-ASTM A216 GR WCB
Stem- AISI TYPE 304, 316
Seat- PTFE
Gland Packing- PTFE
Gasket-- PTFE
Design Std- BS 5156
Testing Std- BS 6755-1 /API 598
Leaver- MS
End connection- Flanged End, Drilling as per ANSI B 16.5 150#, 300#
Face to Face- As per ANSI B 16.10
Pressure Ratting- 150#, 300#
Size-1/2" to 6"
Top Entry makes easy maintenance, no need to remove valve from the line
Easy replaceable seats.
No problem of material strucking in the body cavity as found in ball valves
Low pressure sealing
The plug design automatically compensates for seat wear as well as thermal expansion.
It provides bi-directional shut off
Different soft seats are available (CFT, GFT, PEAK, VITON, NITRILE, SILICON, EPDM)
Also available in stainless steel.
Company Details
Focusing on a customer-centric approach, HI-TECH CONTROLS has a pan-India presence and caters to a huge consumer base throughout the country. Buy Valves in bulk from HI-TECH CONTROLS at Trade India quality-assured products.
Business Type
Exporter, Manufacturer, Supplier
Employee Count
45
Establishment
1987
GST NO
24AAAFH7195K1Z4
