Low Pressure Die Casting - 1400 Mm X 1000 Mm Tie Bar Space, 350 Kg Melt Capacity, Defect-free Casting With 20-step Pressure Control, Automated Process With Controlled Solidification

InspirOn has acquired state of the art Low Pressure Die Casting machine from Kurtz-Germany as a strategy to provide complete Die Casting solutions under one roof.

Some of the salient features of the machine are
* Space between tie bars : 1400 mm x 1000 mm
* Melt carrying capacity : 350 kg
* Options of one or two central positions for metal entry to the mould.
* Cavity filling through 20 steps pressure control which leads to defect free casting
* Advantages of LPDC Technology
* Controllable filling of the mould (filling against gravity force) - no turbulence, less oxide films, better mechanical properties
* Metal is kept within a closed vessel (metal bath surface not disturbed or ruptured) - cleaner material
* Operation under a protected atmosphere - low hydrogen content
* Controlled solidification with pressurized furnace (higher yield than with conventional risers) -higher yield
* Completely automated process - less human errors
