Load Cell (Model : Ss 410)

Our organization is Exporting, Manufacturing, Distributing, Supplying and Trading to our clients a concentrated wide choice of Load Cell (Model : SS 410) in Ahmedabad, Gujarat, India.

Features:

Wiring Scheme
Single point capability for platform scale
Low profile
Centre loading
Minimum error for OFF
Supports the pan size of 750 x 750 mm
100 kg. to 1500 kg. capacities
Compact and light weight
Hygienic applications like food, dairy & pharma industries and corrosive applications like chemical industries.

Product Specification

Standard Capacities :100, 150, 200, 300, 500, 750, 1000, 1500 kg
Excitation Voltage :10 VDC- Maximum 15 VDC
Nominal Output 2.0 m V/ V
Non - Linearity :< 0.025% FSO
Hysteresis :< 0.02% FSO
Non-Repeatability :< 0.01% FSO
Creep (30 minutes) :< 0.03% FSO
Zero Balance :1.0% FSO
Input Resistance :390 - 15 Ohms
Output Resistance :350 - 5 Ohms
Insulation Resistance (50 VDC) :> 1000 Mega Ohms
Cable Length (4 Core Screened) :3 mtr. Minimum
Safe Overload of Rated Capacity :150%
Ultimate Overload of Rated Cap. :250%
Temp. Compensated Range :0-60 C
Temperature Effect on Output :< 0.0015% FSO/ 0 C
Temperature Effect on Zero :< 0.0020% FSO/ 0 C
Eccentric Load Effect :< 0.02% of FSO at 1/3 rated load placed within the specified sized platter
Deflection :< 0.5 mm at FSO
Tightening Torque :5 m.kg.
Finish & Construction :Electroless Nickel Plated Tool Steel
Environmental Protection Class: IP65
