Shuttering Clamp Led Daytime Light

With
the help of our highly skilled professionals, we are offering our
clients supreme quality LED Daytime Light.
It is specially designed as
a green product for automotive with RDW Emark-4 certificate.
Proposed product is equipped with constant-current controlling
technology, so it can be lighted equably with full color.
This product is highly
popular among our clients for its low price, high quality, pollution
free, noise-free operation and resistance to electronic interferer.
Further, this LED Daytime Light is
available in varied specifications as per the requirements of
clients.

Features:

Specification:

1).Product name:

LED Daytime Running Light

2).Model:

ELN--H005

3).Certificate Name:

DRW Emark-4

4).Certificate No.:

E4 --87R-- 000011

5).Whole kits Consist:

Two LED lamps (Left one and right one), wiring, one paper gift box, user manual

6). Lamp Consist:

Electronic circuit board, viewfinder, wiring, lamp hull and housing;

7). Electronic circuit board:

5 high-power LEDs and Controlling gear

3.Major Technology Parameters:

Rated Working voltage: DC 12V

Rated Working current: DC 1.12A

Rated Power consumption:13.44W

Limb darkening current: DC 0.66A

Limb darkening Power consumption: 7.92W

4.Maximum Technology Parameters:

1). Maximum working voltage: DC 24V, 1 minute only;

2).Over working voltage: DC 18V, 1 hour only;

3).Continuously working time max than 24hours: maximum current range less thanA A Aca A A a A A 2mA

4).Maximum surface temperature:less than 60C(Extraventricular temperature:20C).

5. LED bulb technology parameters:

1).Bulb Color temperature range: 6,000K-6,700K

2).Power: 1W(each LED bulb)

3).Rated working current: less than300 mA

4).Current stablilty:less than A A Aca A A a A A 2 mA (in 24 hours)

5).Brightness is between 70 to 90 LM

6. Electronic Protection:

1). High-Voltage Protection:

The control system will stop working automatically to protect the control module from damage when the power voltage is higher than 15.5V, then LED light only works by the outer power directly;

2). Low-Voltage Protection:

The LED light will shut off to protect the system once the voltage is lower than 9v;

3). Lose-Frequency Protection:

The LED light shut off once the control frequency is abnormal to protect the control module and LED light.

4).Wrong-Connection Protection:

It is no harmful to circuit when the three cables of LED were connected incorrectly. The LED light is off when connection is wrong, it will be on when connection is right. The three cables of LED light are VBB, Vss and VC respectively.
