Lap Type Burners

We offer premium quality LAP Type Burners, which are manufactured function efficiently. These are easy-to-operate and maintain. Made up of superior quality alloy of cast iron, the burner comes with stationary atomizer, which can be removed for cleaning up the burner. Our burners minimize the frictional losses due to constructional effectiveness.

The working principle is effective as mixed fuel-oil combination is atomized by low pressure inside the burner and therefore effective combustion of gases with high CO2 content takes place. The output of the burner can be controlled with the oil regulation adjustments. The swirler flap provided with the burner controls the flame adjustment.

The turn down ratio of 1.4:1 with primary air supply can be further improved by using secondary air. The fuel is supplied either by the Gravity feed system or by the pump at a pressure of 0.7 Kg/cmm2g. The centrifugal blower imparts the atomized air at a pressure of 500-1000mm.W.g.

Different classes of liquid fuels can be used even without preheating. Only heavy oil should be preheated to lower its viscosity for proper atomization.

Applications

Extensively used in industrial furnaces and boilers, the burners are utilized in following industries

* Glass
* Bricks and Ceramics
* Bakery Ovens
* Klins and Galvanizing equipment
* Varnish Pots
* Tea Dryers
* Chemical Plants
* Rolling Mills
* Boilers
* Gasifiers
