Kamsons Binocular Microscope With Digital Camera

Following Details of KAMSONS Binocular Microscope With Digital Camera :

A Robust stable & big body.

OBJECTIVES :

All objectives are antifungal coated infinity corrected long barrel long working distance at the highest numerical aperture such as (Plan) PL4X NA 0.10 10X NA 0.25 40X NA 0.65 (S.L) and 100X NA 1.25 oil immersion (S.L) for brilliantly sharp & flatter images.

EYE PIECES :

High Eye Point Anti Fungal & Anti Reflected Extra Wide Field 10x paired eye piece.

BINOCULAR EYE PIECE TUBES

All prism have Anti- Reflected & Anti a Fungal coatings. Binocular and Trinocular Head having 30 degree Inclination 360 degree rotatable.

NOSE PIECE

A reversed type nosepiece running on Ball- Bearing Balls ensures smooth motion.

MECHANICAL STAGE

Low positioned Co-axial calibrated double plate mechanical stage with feather touch movement.

FOCUSSING MECHANISM

Co-Axial coarse & fine focusing mechanism based on four step reduction gears system which runs on ball a bearing Guideways is provided with special tension adjustment ring. Stopper system is provided so that the slides may not damage.

CONDENSER

Parabolic Aspheric Abbe Condenser NA 1.25 rack & pinion adjustment.

LIGHT SOURCE

6 Volt 20Watt a Halogen lamp adjustable brightness built in field of view diaphragm ensures correct positioning of condenser for perfect illumination of the specimens.

Specification of digital camera

Nikon camera 12 mega pixels (software CD Data cable RC to RC cable Charge
