Industrial Ac Drive - V1000 Series, 1/8 To 25 Hp , Led Display And Dual Microprocessor Logic

• Dual microprocessor logic
• LED display
• Motor & drive overload protection

V1000 Series AC Drive

Performance Features

• Ratings: 1/8 to 5 HP at 240 VAC 1-ph, 1/8 to 25 HP (ND) at 240 VAC 3-ph, 1/2 to 25 HP (ND) at 480 VAC 3-ph
• Overload Capacity: 150% for 60 sec. (Heavy Duty) 120% for 60 sec. (Normal Duty)
• Control Methods: V/f Control,
  Open Loop Current Vector Control,
  PM Open Loop Current Vector Control
  Simple closed loop speed control
• DC injection braking, ramp to stop
• Electronic reversing
• Adjustable accel/decel:0.01 to 6000 seconds

• Current limit, stall prevention during accel, decel, and run
• Motor and drive overload
• Over voltage prevention function

• UL 508C (Power Conversion)
• CSA 22.2 No. 14-95 (Industrial Control Equipment)
• UL, cUL listed; CE marked.

• Dual microprocessor logic
• Digital keypad operator, 5 digits
• LED status display
• Remote Mount Keypad Capability
• RJ-45 Style Digital Operator Connector
• 7 multifunction digital inputs Connector
• Programmable form C output contact for customer use: 1A at 250 VAC or 30 VDC
• Hardwire baseblock (EN954-1 Cat. 3)

• Ambient service temperature:
  -10 to 40C (14 to 105F) NEMA 1
  -10 to 50C (14 to 122F) Open Chassis
• Ambient storage temperature:
  -20 to 60C (-4 to 140F)
• Humidity: to 95% non-condensing

• Dynamic Braking resistor (external)
• Multi-lingual, full-text remote LCD
• Profibus-DP, DeviceNet Communications.
