Horizontal Rectangular High Pressure Autoclave Chamber Size: 180 Liters 250 Liters 320 Liters 430 Liters

The Inner/Outer chamber, steam jacket and boiler are made of heavy gauge SS with leak proof argon arc welding.
The space between outer chamber and, steam jacket is filled with glass wool to minimize thermal losses.
Hydraulically tested to with stand 2.5 times the working pressure.
Steam boiler is fitted with water level indicator, pressure gauge, low water cut off device and automatic pressure control devices, fitted with safety valve as a safety device.
Drain valve is fitted at the side bottom for easy draining/clearing.
This affords a complete safety to the working personnel against explosive opening.
Two separate valves are provided for evacuating steam from inner chamber and jacket as when desired.
Sterilization cycle is controlled by single multiport valve.
The chamber discharge line is fitted with a moisture trap to absorb the condensate automatically thus preventing moistening of the loaded material to be sterilized.
An automatic vacuum breaker is fitted to all the units as standard accessory in order to break the vacuum in case of steam condensation.
The flanged immersion type heating element made from a very high grade material provide fast formation of pressure in the system and one protected through a electric low water level cut off device.
All sterilizers are provided with triple safety features through a Piezostate (automatic pressure control system) & a spring loaded safety valve fitted to the boiler/steam generator.
The chamber is fitted with spring loaded safety valve and dead weight release valve.
To work on 220/230 or 440 volts, 3 Phase, 50 Hz AC supply.
