Horizontal Openwell Pump Set

We are established in Shapar, Gujarat, India and indulged in manufacturing and supplying Horizontal Openwell Pump Set to our customers. The offered Horizontal Openwell Pump Set is manufactured utilizing finest grade raw material and advanced technology to fulfill different needs of customers.

Product Product:
H.P. - 0.50Shut off Suction - 8 Mtrs.Bearing - CRC 1000 Grade
Phase - SingleMax. Head - 40 Mtrs.Seal - Carbon & Ceramic Base
Max. Amps. Range - 1.5 A. to 4.5 A.Max. Discharge - 3000 L.P.H.Copper - 99.99 % Purity
RPM - 2880Bearing - DoubleALu. - 99.98 % Purity
Suc. Size - 25 mmPump Seal - Mechanical SealLTB 3 - TIN 6 to 8 %, Lead 9 to 11 %, Nickel 2%
Del. Size - 25 mmWorking Seal Temp. - 80oCM 45 - Nickel:0.17 to 0.20 %, Carbon : 0.30 to 0.45 %, Silicon : 1.37 to 1.75 %, Copper : 0.15 to 0.20 %
Body Temperature - max. 45oC to 65oCDesign - Total Enclosed Fan CooledCast iron - FG 250 Grade, Carbon : 3.20 to 3.60 %, Silicon : 1.8 to 2.20 %
Voltage Fluctuation : +15%, - 20% Max. (at Declare Voltage)Working at Water Temp. - 80oCMild Steel - Forged
