Horizontal Boring And Milling Machine By Kalpesh Machine Tools
Price:
Get Latest Price
In Stock
Product Specifications
| Spindle Speed | 208-1000 Rpm |
| Table Size | 900 X 1120 Mm |
| Max. Bore | 450 Mm |
| Max. Facing | 800 Mm |
| Workpiece Weight | 2000 Kg |
| Material | Steel |
| Spindle Taper | Mt5 |
| Features | Precise Boring, Efficient Milling, Heavy Duty, Versatile Machine, High Accuracy, Durable Design, Large Capacity, Easy Operation |
| Payment Terms | Others, Telegraphic Transfer (T/T) |
| Delivery Time | 2 Week |
| Sample Policy | Contact us for information regarding our sample policy |
| Main Export Market(s) | Asia |
| Main Domestic Market | All India |
Product Overview
Key Features
Salient Features:-
Horizontal Boring, Milling & Facing Machine
MODEL - BMT - 80
Spindle Head with Facing Slide1Diameter of work80
2Work spindle movement710
3Max. diameter - boring450
4Max. diameter - facing800
5Spindle Nose taper (Morse)MT5
Feed, Drive & Distribution Gear Box6Rotary table clamping surface900 x 1120
7Max. distance of fixed st bearing from facing lead2240
8Table movement Longitudinal (with stay)1250
9Table movement crosswise1000
10Vertical Traverse of head stock900
11Max. weight of workpiece2000 kgs.
12Rotary table T - slotts width / distance22 / 125
Carriage & Work Table13Rotary table centering diameter90 H 7
14Facing and diameter500
15Facing slide travel200
16Facing Head T - slots, width / distance18 / 300
17Facing Head centering diameter250 H 7
18Facing slide T-slots, width / distance12 / 125
19Fixed stay bearing bore diameter100 H 7 (80 H 7 with with bush)
Boring Stay
20Fixed stay bearing length120
21Spindle Speeds :
A. Range I for spindle and facing head6 Steps 208-16 RPM
B. Range II for spindle and facing head.6 Steps 22.4-125 RPM
C. Range III for spindle.6 Steps 180-1000 RPM
22Rapid idle traverse per minute identical for all movements except radial slide of facing head1400 mm
23Rapid traverse per minute of radial slide of facing head280 mm
