High Speed Spiral Rolling Shutter

Speed : Up to 2.5m/s (98.43 inches/second) with servo drive. Maximum speed depends on door size.
Size : Minimum: 1000mm(3.28'DOW) x 1000mm(3.28'DOH)
Maximum: 8000mm(26.25' DOW) X 9000mm(29.53'DOH)
Panel Material : 0.7mm(0.028") thick is for aluminum platefoaming density is 45kg/m3(2.8lb/ft3) thickness is 43mm(1.69") and 80mm(3.15") the height is 220mm(8.66") for single panelcolor : white(RAL9016); silver(RAL9006); grey(RAL7045); aluminum original color
Drive System : Using three kinds of servo-motor: 0.75KW, 1.5KW and 2.2KW.A A This depends on the door size.A A Each motor assembly is with gearbox and brake. Servo-drive control the running of motor. motor drive the panel through the transmission chain and drive shaft and lift chain. The tension spring will counterbalance the weight of panel.
Electrical Requirements : Standard : 220V/1PH/50/60Hz(servo-motor)
Oversize Door : 380V/3PH/50/60Hz door sizes greater than 36mA (for 36mm thick panels) and 30mA (for 80mm thick panels)
Vision Options : The material is transparent PC with a thickness of 2mm.
For 80mm thick panels the dimensions are 422mm (16.61 inches wide) x 168mm (6.61 inches high)
For 43mm thick panels the dimensions are panel width through, 140mm high
Control Box : Servo-drive, metal enclosure size: 250mm (9.84"W) X 450mm(17.72"H) X 150mm(5.91"D)
Panel Retention : Guide rollers maintain panel tension over the entire length of the side frame. When the door width is less than or equal to 3M (9.84 ft.), the wind pressure is 32 M/S (3.5 KPA, 71.6 MPH).
Larger doors will have wind pressures below this value.
Safety Features : low level: one pair of photoelectric sensors and wireless airbags
High Level : Two pairs of photoelectric sensors and wireless airbags
Option : Light curtain
Lift style : Round Spiral, Oval Spiral
Warranty : 13 months after delivery
Low Level : 70,000 cycles or 1 year
High Level : 150,000 cycles or 2 years

Advantages
Rapid Operation: Opening speed adjustable from 0.8m/s to 2m/s. Utilizes the Archimedean spiral principle with a double-layer turbine structure to reduce resistance and friction, ensuring smooth, high-speed operation.
Wind Resistance and Insulation: Door panels feature a patented thermal break design for superior insulation, meeting National Standard Level 3 for insulation. Can withstand winds up to level 12, with wind resistance rated at National Standard Level 3.
Low Failure Rate: Capable of thousands of open/close cycles per day. Over 1 million cycles of operation without failure.
Intelligent and Convenient: Multiple intelligent opening options, including radar, geomagnetic, remote control, Bluetooth, and app. Features one-touch start, interlock, linkage, and customizable options based on needs.
