Vinyl Cutting Plotter With Super Steel Blade Cutting Speed: 900 Mm/s

Quality : Optimum
Brand : Graphtex
Compatible OS : 12, Cutting Master
Alignment Accuracy : Maximum 0.3 mm with printed image (when reading registration marks specified by this machine)
Pen Type : Oil-based ballpoint, Water-based fiber-tip pen
Blade Type : Super steel
Repeat Ability : Max. 0.1 mm in plot up to 2 m (*1)
Maximum Cutting Force : 4.41 N (450 gf) in 38 steps
Maximum Acceleration : 69.55 ft (21.2 m/s2), at 45Deg. Direction
Cutting Area of Guaranteed Accuracy : 584 mm x 5 m(*1)
Programmable resolution : GP-GL: 0.1 / 0.05 / 0.025 / 0.01 mm, HP-GL: 0.025 mm
Power consumption : 120 VA
Operating environment : 10 to 35 Deg. C, 35 to 75 % R.H. (non-condensing)
Number of push rollers : 2 Rollers
Mountable number of tools : 1 tool
Mountable media width : Min. 1.97 in to Max. 28.03 in (Min. 50 mm to Max. 712 mm)
Minimum character size : Approx. 5 mm alphanumeric (varies depending on character font and type of media
Maximum Cutting Area : (603 mm x 50 m) (*1)
Interface : RS-232C, USB2.0
Guaranteed accuracy environment : 16 to 32 Deg.C, 35 to 70 % R.H. (non-condensing)
Display : Graphic type LCD with back-light (240dots x 128dots), supports 10 languages
Configuration : Grit roller with digital servo drive system
Command sets : GP-GL / HP-GL emulation (Set by command or auto-detect)
Classification : Single-blade Cutter
Buffer memory : 2 MB
