High Accuracy Rotary Separator Vibrating Sieve Machine

We are indulged in producing and supplying of High Accuracy Rotary Separator Vibrating Sieve Machine to our consumers. SENYOU applied in chemicals is our self-developed products.Senyou high frequency stainless steel vibrating sieve is a screening device designed to separate solids from liquids,segregate smaller particles from larger particles,and to remove foreign matter.

Technical Parameters:
Model Power(kw) Diameter of screen(mm) Dimension(mm3)
SYD-600-S 0.25-0.55 550 800*800*750
SYD-800-S 0.55-0.75 760 900*900*750
SYD-1000-S 0.75-1.50 930 1160*1160*810
SYD-1200-S 1.10-1.75 1130 1360*1360*885
SYD-1500-S 1.50-2.20 1430 1850*1850*990

Features:
1.Small amplitude/ high frequency/2900r/min
2.More apparent in screening materials of fine grain and high viscosity
3.High efficiency and energy consumption which means it can spare half energy and double volume
4.Low noise , simple construction /move freely/the height could be adjusted
5.Simple installation and operation/a long use life of motor /even in 24 hours it could be still in a good performance of separating in the bad working condition
6.IP 54 protection rank and class F insulation level
7.The parts contact with materials are made of stainless steel which gaves it abeautiful appearance
