Harris Brazing Rod - Copper Alloy With 7.0-7.5% Phosphorus | Optimal For Copper To Copper Applications, Various Sizes Available

We are manufacturing a wide range of Harris Brazing Rods. Our Harris Brazing Rods are available in various sizes and specifications. These Harris Brazing Rods can be customized as per our customers specifications and availed at industrial leading price.

NOMINAL CHEMICAL COMPOSITION:
Phosphorus : 7.0-7.5%
Copper : Remainder
Other Totals : 0.15% Maximum

PHYSICAL PROPERTIES:
Solidus : 1310oF(710oC)
Liquids : 1473-1476oF(800-802C)
Brazing Temperature Range: 1300-1500oF(704-816oC)
Specific Gravity : 8.76
Electrical Conductivity : (IACS%)9.91
Electrical Resistivity : 19.20

BRAZING PROPERTIES:
Designed primarily for copper to copper brazing application, Harris O is an economical alloy for use where joint clearances are close; less than 0.005". Harris o flows quickly, and may be used in brazing brass with the use of Stay-Sillv brazing flux. Harris O is not recommended
for brazing steel or other ferrous metals.

AVAILABLE FORMS: Standard wire diameters, preformed rings.
