Gear Pump (Model Ft) - Cast Iron, 5-500 Lpm, 10 Kg/cm, 1440 Rpm | Self-priming, Bi-directional, Durable

Authorized in the market as one of the trustworthy manufacturer, exporter and supplier a wide assortment of Gear Pump (Model FT) in Ahmedabad, Gujarat, India. Fluid tech systems offer a rotofluida make gear pump model a fta which is self priming, foot mounting type positive displacement rotary gear pump. Model a fta having simple two pieces cast iron construction which is single helical modified profile carton steel gear shrink fitted on alloy steel hardened and grind finished shaft as gear firmly supported 4 nos. Of self lubricated sintered bronze bush bearing which ensure smooth running. These pumps can be run in either direction with change in inlet-outlet port position. The relief valve operations can be reversed by simply changing the r. V. Parts on opposite side. The suction and delivery connections are available in 1/4" to 3" sizes. These pumps can be operated up to pressure of 10 kg/cmA with 5 LPM to 500 LPM flow capacity. These pumps are designed to run at 1440 rpm up to viscosity of 50, 000 ssu and maximum temperature up to 200A c. It is desirable to reduce speed for size above 1A " performance at low speed is always advantageous as it improves efficiency, reduce noise level and enhances operational life. The capacity will reduce in proportion to the speed.
