Gear Pump Demonstration Unit - Stainless Steel Tanks , Compact Setup For Hydraulic Fluid Mechanics Labs And High Viscosity Fluid Applications

Gear Pump Demonstration Unit - MTS-12070

The Gear Pump Demonstration Unit uses a gear pump, that is widely used of the positive action rotary pumps. Two gear wheels are operational from inside a casing. One gear wheel is driven whilst the other gear wheel rotates in mesh with it. Liquid is transported in the space between consecutive teeth and then ejected as the teeth mesh. This pump has no valves. This positive displacement pump is designed to deliver against high pressures. It can be used for high viscosity fluids.

Experiments of Gear Pump Demonstration Unit

To measure overall as well as pump efficiency of the gear pump.
To plot Head vs. Discharge, Pump efficiency vs. Discharge
Features of Gear Pump Demonstration Unit

SS tanks and wetted parts
Painted structure
Closed loop circulation
Compact set up
Simple operations & maintenance
