Ftth Drop Fibre Cable

We are Making and Distributing FTTH Drop Fibre Cable in Changsha, Hunan, China. The optical fiber units is positioned in the centre. Two parallel fiber reinforced plastics(FRP) are placed at the two sides. Asteel wire as the additional strength member is also applied. Then, the cable is completed with a black or color LSZH jacket.
A
A
1) Outdoor Single Mode G.652D/G.657A1 LSZH Sheath Optical Fiber
A Singlemode: G652D, G657A1 G657A2 etc
2)Strength memberA i
A Amount2 PCS
A MaterialMetallic, FRP, KFRP
A Diameter0.50A 0.10 mm
3) A A A Fiber counts: 1~12 cores
4)Outer sheath of Outdoor FTTH:
A MaterialPVC or LSZH - Low smoke zero halogen
A ColorWhite, Black
A Diameter2.0 H A 3.0 W A 0.1 mm OR 2.0 H A 4.0 W A 0.1 mm
A MarkingAs per Customer Request

A Tensile properties
No.ItemUnitsIndex
1Pulling Load (short time)Na 80
2Pulling Load (long time)Na 40
3Crush load (short time)N/100mma 1000
4Crush load (long time)N/100mma 500
5Bend radius ( static )mma Y 15
6Bend radius ( Dynamic )mma Y 30
A Environmental conditions of Outdoor FTTH Cable
No.ItemUnitsIndex
1Storage temperature rangea -40 to +70
2Install the temperature rangea A -0 to +50
3Operating temperature rangea -20 to +70
A Package of Outdoor FTTH Cable
No.ItemA Index
1Length and packaging1000m/Plywood Reel
2Plywood reel size250A 110A 190mm
3Carton size260A 260A 210mm
4Net weight21 kg/km
5Gross weight23 kg/Box
