Ft12 Electromagnetic Flow Meter - Accuracy: 0.5% Of Reading

Get Latest Price

Minimum Order Quantity :

In Stock

Product Specifications

Pressure Range	0-16 bar
Color	Silver & Blue
Stability	High stability over long term
Output	4-20mA, Pulse, RS485 MODBUS
Length	Varies by DN (consult datasheet)
Process Connection	Flanged (ANSI/DIN/BS)
Model	FT12 Electromagnetic Flow Meter
Storage Temperature	-20C to +60C
Protection	IP65 / IP67 / IP68
Temperature Range	-10C to +60C
Input	Pulse / Analog Input
Language	English
Measuring Units	m3/h, L/min, L/h, etc.
Axis Type	Single Axis
Housing Material	Powder-Coated Aluminum & Stainless Steel
Connecting Type	Flange
Load Capacity	Configurable
Connector	Screw terminal
Frequency	50/60 Hz
Humidity %	0-95% RH non-condensing
Current Range	4-20 mA
Operating Temperature	-10C to +60C
Resolution	0.001 m3/h
Signal Type	Analog & Digital
Velocity Range	0.3 - 10 m/s
Application Media	Conductive Liquids, Water, Acid, Slurry
Mounting	Flange Mounted
Cut Size	As per process requirement
Equipment Type	Electromagnetic Flow Meter
Flow Rate	Up to 6000 m3/h
Sensitivity	0.5% of reading
Diameter	DN10 to DN600
Measurement Range	up to 6000 m3/h
Capacity	Varies by model
Response Time	<1s
Connectivity Type	Wired
Dimension (LWH)	Varies as per diameter
Sensor Type	Electromagnetic
Material	Stainless Steel / Carbon Steel with PTFE/Rubber Lining
Power Supply	230V AC / 24V DC
Power Consumption	<20 VA
Accuracy	0.5% of reading
Display Type	Other, Digital LCD or LED
Range	0.3 - 10 m/s
Payment Terms	Cash in Advance (CID)
Supply Ability	100 Per Month
Delivery Time	5-7 Days
Main Domestic Market	All India
