Ft02 Electromagnetic Flow Meter

Price:

Get Latest Price

Minimum Order Quantity :

In Stock

Sensitivity	High sensitivity
Connecting Type	Flange Connection
Velocity Range	0.3~10 m/s
Measuring Units	Liters, Cubic Meters, Gallons
Measurement Range	0~10,000 m3/h
Current Range	4-20mA output
Model	FT02 Electromagnetic Flow Meter
Pressure Range	Up to 1.6 MPa
Dimension (LWH)	Depends on model size
Frequency	50/60 Hz
Humidity %	0-95% RH (non-condensing)
Connector	Screw / Flange
Mounting	Flanged
Process Connection	Flanged
Response Time	0.5 seconds
Storage Temperature	-20C to +70C
Temperature Range	-10C to +60C
Equipment Type	Electromagnetic Flow Meter
Stability	High stability, industrial grade
Protection	IP65 / IP68
Capacity	Varies by diameter
Language	English
Flow Rate	As per pipe size and velocity
Sensor Type	Electromagnetic
Application Media	Conductive Liquids
Resolution	0.001 m3/h
Color	Blue
Input	220V AC
Housing Material	Powder-coated Carbon Steel
Load Capacity	Depends on meter size
Signal Type	Analog and Digital
Connectivity Type	Wired
Diameter	Available from 15 mm to 600 mm
Cut Size	As per model
Operating Temperature	-10C to +60C
Output	4-20mA, Pulse, RS485 Modbus
Length	As per selected model
Material	Carbon Steel with PTFE Lining
Power Supply	220V AC, 50/60 Hz
Power Consumption	<20W
Accuracy	0.5% of reading
Display Type	Other, LCD Digital Display
Range	0.3 to 10 m/s
Payment Terms	Cash in Advance (CID)
Supply Ability	100 Per Month
Delivery Time	5-7 Days
Main Domestic Market	All India
