Turbine Flow Meter - Stainless Steel Enclosure, 4 To 50 Mm Line Size, 1% Accuracy | Digital Display, Battery Operated, Power-fail Protection, Resettable Cumulative Flow

Having best market approach, we "BROIL SENSOTEK INDUSTRIES" are engaged as manufacturer, supplier, trader and exporter of a wide range of Flow Meter in Mehsana, Gujarat, India. We offer turbine flow meter with digital display battery operated.

Specifications:
Model no: BT- ETFS a SS-LINE SIZE,
Make: BROILTECH
Material of construction:
Enclosure : Stainless steel / Aluminum anodized
Rotor : PPS / PA66 33GF
O-ring : NBR / Viton
Shaft : Hard Stainless Steel-316
Accuracy : 1% FSD
Repeatability : 0.25%
max. pressure : 100 bar ( high pressure on request)
working pressure : 70 bar ( high on request)
Fluid temperature : -20 to 120 Deg. C
Connection : Thread (M/F) or flange
Battery operated meter :
Power voltage: 3.3 V10AH lithium batteries can be used more than 2 years in a row.
display mode:
Double row Liquid Crystal Display (LCD), as follows: with flow rate and total
Cumulative flow: automatically expand the display precision, the cumulative flow values can be reset.
Power-fail protection: instrument coefficient, the Total flow values ten years is not lost when power supply drop.
Turbine flow sensor model no wise Technical data: ^
Line size Range
04 mm 15 ~ 240 L/H
12 mm 60 ~1800 L/H
20 mm 90 ~3000 L/H
20 mm 400 ~6000 L/H
25 mm 150 ~ 6000 L/H
40 mm 1000~12000 L/H
50 mm 3000~30000 L/H
