Flatbed Cutting Plotter By Rink International Co., Ltd.

Model:
FCX2000 Series

Model:
GRAPHTEC FCX2000-60VC / FCX2000-120VC /FCX2000-180VC /FCX2000-120ES

Flatbed cutting plotter has been widely used
in a variety of applications such as the prototyping of industrial materials,
the small production runs and the post-processing of the on-demand printing. It
is able to run a half-cut and die-cutting in high-mix low-volume without the
use of a cutting die at less cost and short delivery times.

FCX2000 series achieves high quality
cutting with improving of the quality and accuracy by enhancing rigidity of the
sliding mechanism and the driving system.

It is the high-end model of flatbed cutting
plotter that has a high usability and productivity equipped with new functions.

Features:

There are four of the table size and the
two media hold-down method, it is suitable for many applications.

-FCX2000-60VC, Vacuum Suction

-FCX2000-120VC, Vacuum Suction

-FCX2000-180VC, Vacuum Suction

-FCX2000-120ES, Electrostatic

Mark sensor

A set of tool for cutting heavy paper or
cardboard is supplied.

Max. Cutting Force: 1kg (able to cut heavy paper)

Max. Cutting Speed: 400mm/s

Added offline (USB) operation enables users
of all skill levels to easily process materials

Improved application Software other
advanced features is available via plug-ins and optional software for work
efficiency.

Technical Data:

Weight:

-FCX2000-60VC: 76kgs approx.stand included, but pump (blower) for
vacuum suction media hold-down system is not included.

-FCX2000-120VC: 99kgs approx.stand included, but pump (blower) for
vacuum suction media hold-down system is not included.

-FCX2000-180VC: 116kgs approx. (stand included, but pump
(blower) for vacuum suction media hold-down system is not included.

-FCX2000-120ES: 93kgs approx.stand included.

External dimensions [W x D x H] (Approx.):

-FCX2000-60VC: 1344 x 1409 x 930mmstand included

-FCX2000-120VC: 1934 x 1409 x 930mmstand included

-FCX2000-180VC: 2534 x 1409 x 930mmstand included

-FCX2000-120ES: 1934 x 1409 x 930mmstand included

Remark:
This is to replace FC2230 & FC2200 and FC2240 & FC2250 which
were discontinued.
