Fet Characterisitics - Application: Engineering Electronics Instruments
Price: 1400.00 INR / Piece
(1400.00 INR + 0% GST)
Get Latest Price
1 Pack Contains :
1
Minimum Pack Size :
1
In Stock
Product Specifications
| Input | Variable voltage for FET gate and drain |
| Usage | ENGINEERING ELECTRONICS INSTRUMENTS |
| Power Supply | External AC mains |
| Features | Replaceable FET socket, Built-in meters, Rugged construction, Educational labeling, Manual control knobs |
| Interface | Banana-type terminals, Reset/Control Knobs |
| Color | Blue and Black (as per device housing in the image) |
| Power Source | AC mains |
| Operating Temperature | 0C to 50C (typical for laboratory equipment) |
| Components | FET, voltmeter, ammeter, potentiometers, connecting terminals |
| Output | Visual display via analog/digital meters; connection terminals provide electrical output readings |
| Display Type | Other, Analog Meters (Galvanometer/Voltmeter Permanent Magnet Moving Coil) |
| Resolution | Meter/Scale Resolution: 0.1V, 0.1mA (estimated from standard meter types) |
| Response Time | Immediate (analog display type) |
| IP Rating | Not Rated (indoor, laboratory use) |
| Product Type | FET CHARACTERISITICS |
| Application | ENGINEERING ELECTRONICS INSTRUMENTS |
| Rated Voltage | 230 V AC, 50 Hz (mains powered) |
| Supply Voltage | 230 V AC, 50 Hz (mains) |
| Size | Standard desktop trainer size (approx. 320 x 220 mm as visually estimated) |
| Dimension (L*W*H) | 320 mm x 220 mm x 100 mm (approximated from image) |
| Function | To demonstrate and study the characteristics of Field Effect Transistors (FETs) |
| Weight | Approx. 2-3 kg (estimated from device type) |
| Current Rating | Milliamperes (range as per analog meter spec; typically 0-10 mA) |
| Capacity | Supports testing of standard FETs (ex: JFET, MOSFET as per socket provision) |
| Frequency | 50 Hz (mains for power supply) |
| Payment Terms | Cash on Delivery (COD), Cash Advance (CA), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C) |
| Packaging Details | Carton Box, Export Quality also Available |
| Main Export Market(s) | Asia, Middle East, Africa |
| Main Domestic Market | All India |
| Certifications | ISO 9001, 14001, CE |
| Moq | 1 |
| Price Type | fixed |
| Unit Type | Piece/Pieces |
| Currency | INR |
| Color | Blue and Black (as per device housing in the image) |
| Mop | 1 |
| Product Unit | 1 Piece/Pieces |
| Packsize | 1 |
| Brand Name | EDUTEK |
| Stock Quantity | 5 |
| Returnable | No |
| Price | 1400.00 INR (Approx.) |
| Minimum Order Quantity | 1 |
| Minimum Ordered Packs | 1 |
| GSTIN | 0% |
Product Overview
Key Features
FET CHARACTERISITICS
FET Characteristics to demonstrate the operation of a Field Effect Transistor (FET) characteristics and testing methods.
To examine the relationship between the gate-to-source voltages (VGS), drain current (ID) and the drain-to-source voltage (VDS) in an N channel junction FET.
To measure and record correspondingly the VGS, ID and VDS values and then plot these values to form a set of drain characteristic curves.
To complete the experiment using these curves to determine the Trans conductance of the FET.
