Fasteners Optical Sorting Machine

With our proficiency in the domain, we are indulged in exporting, manufacturing and supplying an excellent quality array of Fasteners Optical Sorting Machine in Ruian, Zhejiang, China.
PRODUCT FEATURE
a cAppyling component: Fasteners, screws, nuts, bolts, and so on
a cSuitable for inspecting all kind of fasteners
a cSorting range: M1~M20
a cApplication: all kind of fastener, screws, nut, bolt and so on
a cSpeed: Non-stop Inspection with High Speed 600~1000 parts per minute
a cuser-friendly ,easy for operation and maintenance

Inspection criteria
Eddy current: inspection hardness, material mix, with /without heat treatment
parts head width / height / pinhole depth / recess shape / burr in recess/ spiral thread / thread I.D. / thread E.D./ neck length / shank vertical / screw length / first thread / drunk thread / head crack / plating / insert nut thread / burr / dimension / etc.

Specification
Appling component: screw, nut, bolt, other fasteners
Diameter of component: M1-M20
Length of component: up to 120 mm
Head Width: 25mm
No. of CCD: 1~5 CCD
Vision system: Highly magnified CCD camera / light source sets
Software: Eyason II version 2.5
Supply and output: Feeding bowl / linear track / sorting bins (Good/NG)
Speed: 200~1000 pcs/min
Power: AC 220 - 240V / 50Hz
