Fa206c High Production Cotton Carding Machine - 1000mm Working Width, 280m/min Delivery Speed | Intelligent Control, Easy Operation, Safety Protections

With the help of our team of experts, our company known as a leading Exporter and Supplier of FA206C High Production Cotton Carding Machine in Qingdao, Shandong, China.
i Intelligent control
Advanced monitors control system.
The working status and running efficiency .
Safety protections and self-diagnosis system .
i High quality and high efficiency
Sophisticated suction system provide better opening and cieanina .
Independent transmission motors adjusted by inverters for high efficiency.
i Easy operation and maintenance
User friendly graphical interface .
Easy access to control parameters .
Smart mechanical design makes maintenance an easy task .
ApplicationThis machine is used for processing cotton and man-made fiber or blends in length 22-76mm
Production (kg/h)80
Delivery speed (m/min)280
Lap size(mm)Max diameter:550 Width:980
Feed weight(mm)300-1000
Sliver count(g/m)3.5-7
Total draft60-300
Working width1000
Licker-in diameter(mm)I 250
Licker-in speed(r/min)833 942 1025
771 872 949
712 805 877
Doffer dia(mm)I 706
Doffer speed(rpm)8-60
Cylinder dia (mm)I 1288
Cylinder speed (rpm)340-467
Number of revolving flat(working/total32/86
Flats speed(mm/min)81-334
Auxiliary carding segmentCarding segment underlicker-in:2 pieces
Rear stationary flat:4(cotton) 4-6(chemical fiber)
Front stationary flat:4(cotton) 4-6(chemical fiber)
Can size(mm)Diameter 600,1000,height 1100,1200
Continuous suction(mA /h)Air volume 3500
Air pressure(pa) -850i -920
