Electromagnetic Hammer - High-grade Strip Lamination, Compact & Maintenance-free Design | Prevents Clogging In Spray Dryers, Cyclones, Hoppers, And Ducts

NEC Electromagnetic Hammers are compact, maintenance free, operates better than any other conventional hammering system
Electromagnetic Hammers prevent clogging and adhesion of powdery and granular materials in Spray Dryers, Cyclone, Hoppers, BINS, Powder conveying ducts, etc

Operational Features
Electromagnetic Hammer consist of a stator and rotar, which are made out of high-grade strip lamination to minimize iron losses. There are two salient poles on the stator over which excitation coils are placed. When the hammer is excited by a short duration electric pulse the rotor takes the position of minimum reluctance to magnetic path. The part movement of the rotar shaft is directly transmitted to hammer stroker. The stroker in turn hits the hopper with strong force and returns to the original position. The excitation of hammer coils is controlled by an electronic controller.clients for offering cost-effective products that are precisely designed according to the clients' specifications. Consequently, we have garnered a rich clientele belonging to different industrial sectors.
