Easy Loading Thermal Printer Module - Ultra Compact Design, 60 Mm Paper Roll Diameter, Integrated Control Board With Serial Communication | Superior Error Indications, Self-test, Selectable Font Sizes, And Programmable Speed

Easy Loading Printer Modules with an integrated control board using serial communication protocols.
The module consists of a set of mechanical and electronic parts designed to have a high grade of integration and to perform many different functions.

FUNCTIONS SUPPORTED:
Graphics Printing
60 mm paper roll diameter
Selectable font size
Options for using regional fonts
Error Indications: Out of Paper, Head
temperature high
Option of Economy mode with lower current
Self-Test

FEATURES:
Ultra Compact Bucket Printer
Complete text and graphic printing
Industry compatible paper roll container
Inbuilt over temperature and voltage protection
2 inch paper width
Superior mounting provision
APS thermal printer mechanism
Clips for greater mounting stability
24 characters per line by default
Head temperature protection
Programmable speed up to 50 mm/sec
Serial RS-232 interface
Universal ESC sequence compatible
Single supply operation a 5V
