Ecg Machine- Nemo I

Ecg Machine- Nemo I

Features:

• Ergonomic and lightweight design.
• 12 lead simultaneous acquisition.
• Digital isolation technology minimizing time and temperature drift of
• components.
• Digital filtering, resisting baseline drift, AC and EMG interference.
• Automatic baseline adjustment.
• Optional rhythm leads printing.
• Auto / Manual work mode.
• Built in high resolution thermal array printer.
• Built in rechargeable battery, AC / DC power supply.
• Optional big screen display for 12 lead simultaneou acquisitions.

• Lead: Standard 12 leads.
• Circuit: Floating: protection circuit against defibrillator effect.
• Input circuit: 50 ma.
• Patient circuit leakage: <10a.
• Input impedance: 50 M??.
• Calibrating voltage: 1mv2%.
• Skin voltage tolerance: 500mv.
• Sensitivity: 2.5, 5, 10, 20mm/mv.
• Paper speed: 25 / 50mm/sec 2%.
• Time constant: >3.2sec.
• Noise level: 15 Vp-p.
• Frequency response: 0.05Hz - 150Hz (-3dB).
• CMRR: >80dB, >100dB (with AC filter).
• A/D converter: 18bit.
• Recording paper: Roll paper 50mm x 20m.
• Operation mode: Auto / Manual.
• Printer: Thermal array printer.
• Anti baseline drift: Automatic.
• Rhythm lead: II / V5.
• Safety level: IEC60601-1 class, type CF.
• Power requirements: AC 220V, 50Hz / 110V, 60Hz
  DC built in rechargeable battery supporting 50 exams after full charging.
• Dimensions: 310 x 230 x 73 (mm).
• Weight: G.W: 5kg, N.W: 3kg.
