Dry Running Seal - Carbon/silicon Carbide, Ss 316/ss 304, 15-150mm Shaft Diameter, 320 Rpm Max Speed, Reverse Balanced Design | Single Acting, Outside Mounted, Contamination-free Solution For Food And Pharmaceutical Applications

Backed by the years of experience and knowledge, we are engaged in manufacturing and supplying an exclusive range of Dry Running Seal in Sidhpur, Gujarat, India.

Mechanical Seal Series : B88B1A/DG
Standard Style Face Materials : Carbon / Silicon Carbide
Metal Parts : SS 316, SS 304, Hastelloy - C, Hastelloy - B, Monel, Alloy - 20
Secondary Seals : Elastomers
TCV

Application :
a Food Products
a Pharmaceutical Products

Seal Characteristics :
a Single acting
a Reverse Balanced
a Outside Mounted
a Independent of Direction of Rotation
a Dry Running

Operating Limits :-
Shaft Diameter d 15 ...150mm
Pressure p Vacuum .... 8 bar (max)
Temperature t Amb. .... 120O C (max)
Speed n 320 rpm

Series B88B1A/DG is factory assembled & dynamically tested seal for steel, glass lined and SS mixers, agitator & vessels. This is a multiple spring externally mounted; reverse balanced seal with O-ring as secondary sealing member. Various elastomers can be offered for wide service application. These seals are basically used on top entry agitators as dry running seals. When food products or pharmaceutical products are agitated in agitator, mixing of any other liquid will contaminate the product & affect its quality; hence these dry running seals are used. These seals don't require any external media for lubricating the faces that is why they are known as dry running seals.
