Double Color Injection Molding Machine - Robust Build, High Corrosion Resistance, 320mm Screw Diameter, 680kn Clamping Force | Extended Functional Life, Low Maintenance, Enhanced Performance
Price:
Get Latest Price
In Stock
Product Specifications
| Injection Unit Screw Diameter (Mm) | 32, 24, 42, 32, 50, 40, 55, 42, 70, 45 |
| Shot Volume (Cm³) | 110, 240, 550, 710, 1165 |
| Shot Weight (G) | 100, 200, 495, 640, 1050 |
| Injection Pressure (Mpa) | 175, 200, 165, 171, 200, 200, 180, 165, 160, 155 |
| Screw Speed (Rpm) | 2-200, 2-180, 5-200, 2-200, 2-190, 2-200, 2-160, 2-200, 2-160, 2-200 |
| Clamping Unit Clamping Stroke (Kn) | 680, 1380, 2180, 2680, 3680 |
| Platen Stroke (Mm) | 280, 380, 470, 540, 660 |
| Features | High Output, Durable Design, Precise Control, Easy Operation, Cost Effective, Two-Color Molding, Versatile Use, Low Maintenance |
Product Overview
Key Features
Double Color Injection Molding Machine
Fabricated utilizing high quality of raw materials and advanced manufacturing techniques, we manufacture and supply Double Color Injection Molding Machine. These products are used in different types of industries for producing various plastic products by injection molding process. Owing to their robustness, corrosion resistance, low maintenance, longer functional life, immaculate performance and smooth functioning, these products have a high demand in the market. Modified as per the specifications given by the clients, Double Color Injection Molding Machine can be availed from us at industry leading rates.
| Injection Unit | Screw Diameter | Mm | 32 | 24 | 42 | 32 | 50 | 40 | 55 | 42 | 70 | 45 | |
| Shot Volume | cm | i+ii=110 | i+ii=240 | i+ii=550 | i+ii=710 | i+ii=1165 | |||||||
| Shot Weight | G | i+ii=100 | i+ii=200 | i+ii495 | i+ii=640 | i+ii=1050 | |||||||
| Injection Pressure | Mpa | 175 | 200 | 165 | 171 | 200 | 200 | 180 | 165 | 160 | 155 | ||
| Screw Speed | Rpm | 2-200 | 2-180 | 5-200 | 2-200 | 2-190 | 2-200 | 2-160 | 2-200 | 2-160 | 2-200 | ||
| Clamping Unit | Clamping Stroke | KN | 680 | 1380 | 2180 | 2680 | 3680 | ||||||
| Platen Stroke | mm | 280 | 380 | 470 | 540 | 660 | |||||||
| Space Between Tie-bars | mm | 310X310 | 427X405 | 515X515 | 570X570 | 710X710 | |||||||
| Max.Mould Thickness | mm | 380 | 450 | 530 | 580 | 760 | |||||||
| Min.Mould Thickness | mm | 120 | 150 | 200 | 230 | 250 | |||||||
| Ejector Stroke | mm | 80 | 120 | 130 | 140 | 160 | |||||||
| Ejector Force | KN | 28 | 38 | 71 | 71 | 126 | |||||||
| Other | Max.pump Pressure | Mpa | 14 | 14 | 14 | 14 | 14 | ||||||
| Motor Power | KW | 11 | 15 | 30 | 37 | 45 | |||||||
| Heater Power | KW | 5 | 8 | 15 | 16.7 | 22.4 | |||||||
| Machine Dimensions(LXWXH) | m | 3.40X1.20X1.50 | 4.50X1.20X1.70 | 5.23X1.84X1.88 | 5.89X2.2X2.15 | 7.00X2.10X2.30 | |||||||
| Machine Weight(about) | t | 2.6 | 4.3 | 7.2 | 9 | 15 | |||||||
