Directjet Printer - 10x24" Print Size, Gray, 6-color Uv Led, 5760 Dpi, Prints On Wood Metal Ceramic Plastic Glass, Up To 6" Substrate Thickness

Imaging process

On-demand inkjet (Micro piezo) 8-channel head with 180 nozzles/inch/channel

Resolution

Draft Modes: 360x360, 360x720, 720x720

Production Modes: 720x1440, 1440,1440, 1440,2880 dpi, 1440x5760 dpi

Minimum/Maximum Ink Droplet Size

1.5 picoliters/21 picoliters

Ink Colors

Y,M,C,K,CI,CI,W,W (Cl=clear, W=White)

Print Direction

Uni- and Bi-directional

Control Panel

8-button membrane switch

Maximum print size

1014UV: 10x14 (254mmx355mm)/1024UV:10x24 (254mmx610mm)

Maximum Substrate size

1014UV: 13x14 (330mmx355mm)/1024UV:13x25 (330mmx635mm)

Maximum substrate weight

10 Ibs(4.5 kg) or 20 Ibs(9.1 kg) with optional Y-axis Direct drive stepper module

Media

Prints to a variety of substrates using the DCS Multisolve LED UV IR2 ink set, including (but not limited to) plastic, glass, wood, ceramic, stainless steel ,etc

Interface

Hi-Speed USB 2.0

Windows operating system

Vista and windows 7 (32 & 64 bit)

System Minimum requirements

CPU of >2GHz, >4GB RAM, 40 GB free hard disk space and 2 available USB 2.0 ports

System recommendation

Dual-core CPU of >3GHz, 8GB RAM, 100 GB free hard disk space and 2 available USB 2.0 ports

Power source

100-240 VAC, 50-60Hz, 4A Auto switching

Humidity

Non-condensing 20%-80%

Dimensions

Agency listings

CE

Warranty

Printer 1-year limited warranty
