Digital Flow Meter (P282)

We are manufacturing, exporting and supplying Digital Flow Meter (P282) to our clients in Pune, Maharashtra, India to our clients. NUCLUS model P282 Digital Flow Meter is flow rate indicator cum totaliser. This model can be mount either panel / field mounting. This model have programmable scale factor with direct flow rate reading in M3/hr / LPH / LPM / LPS / GPMus / GPMuk, and totaliser reading in m3 / Liters / Gallon. This model have optional Relay output which is operate on Totalizer (used for Batching and Dosing application ) or operate on flow rate ( used as flow switch) .

Technical Specifications for P282:
FUNCTION- Rate indicator cum Totalizer
DISPLAY - 16 X 2 Lcd display.
SUPPLY VOLTAGE- 230 V AC.
LINEARITY- A 1% of full range
REPEATABILITY- A 0.5% of full range
INPUTS- Nuclus flow sensor (P812)
CONFIGURATION LOCK- Password protection.
CALIBRATION- Using front membrain keys
OUTPUT- 5A pot. Free Relay @230VAC
METER SIZE- 110 mm X 110 mm X 150 mm
CUTOUT SIZE- 90 mm X 90 mm
Protection Rating- IP65 for field mounting unit
