Digital Counter - 96x96 Mm, Low/high Speed Operation | Npn Proximity Switch, Manual Reset, Non-volatile Memory

We are engaged in offering superior quality range of Digital Counters to our most valued clients. This range of Digital Counter is available with following specifications:-

Input : NPN Proximity Switch, Micro Switch, Encoder Pulse
Reset : Manual reset at front by push button
Setting : Thumbwheel switch
Output : Relay contact 5 Amp/230V AC
Output : Relay contact 5 Amp/230V AC
Count Rate : Low Speed upto 1000 pulse/min High Speed, beyond 1000 pulse/min
Supply : 230V/110V AC A 10%, 50 Hz.
Optional:-
* Reset terminals at back
* Auto Reset
* Overflow indication
* Pulse divided can be provided (e.g.2:1, 2 pulse for 1 Count)
* Down Counting
* Non-volatile memory to store last count at power fail.

Model DPC - 1400 DPC - 2500
Size (mm) 96 x 96 72 x 72
Cutout(mm) 92 x 92 68 x 68
Depth (mm) 100 120
Range : 3 digit / 4 digit / 5 digit 3 digit / 4 digit / 5 digit
Mounting : Flush panel mounting with side clamps fixed behind the panel

Our prices are affordable and our Digital Counters are outstanding.
