Dc 3 Pin Nato Socket - Cable Diameter: 120 Sqmm

Name: DC 3 PIN NATO SOCKET
Price: 9000 INR
Availability: InStock

Price: 9000 INR / Number

Get Latest Price

Minimum Order Quantity :

5 Number

In Stock

Product Specifications

Sealed	1
Cable Diameter	120 SQMM
Product Type	Other
Application	The DC 3-Pin Female NATO Socket is a rugged, military-grade electrical receptacle designed for reliable 28V DC power transfer in demanding environments. Compliant with NATO STANAG standards and AN2551 specifications, this socket ensures safe, arcing-free connections for external power supply to aircraft, helicopters, military vehicles, and ground support equipment (GSE). It features a three-pin configuration: two larger pins for high-current power (+24V DC) and ground, and a shorter solenoid pin for low-amperage (up to 100W) control circuit activation, preventing electrical hazards during mating/unmating.Ideal for aviation maintenance, vehicle jump-starting via slave cables, and tactical operations, this socket offers superior durability with silver-plated contacts for low resistance and high conductivity. Constructed from impact-resistant polycarbonate housing (typically red for easy identification), it withstands extreme conditions including vibration, shock, and temperature fluctuations. Panel-mountable with threaded flange for secure installation on bulkheads or chassis.This connector supports up to 500A peak current (with appropriate cabling) and is widely used in small general aviation aircraft, helicopters, and NATO-compatible military systems. Variants available for custom wiring or environmental sealing. Bulk orders welcome for exporters and OEMs.
Warranty	1 Year
Fittings	SS
Usage & Applications	The DC 3-Pin Female NATO Socket is a rugged, military-grade electrical receptacle designed for reliable 28V DC power transfer in demanding environments. Compliant with NATO STANAG standards and AN2551 specifications, this socket ensures safe, arcing-free connections for external power supply to aircraft, helicopters, military vehicles, and ground support equipment (GSE). It features a three-pin configuration: two larger pins for high-current power (+24V DC) and ground, and a shorter solenoid pin for low-amperage (up to 100W) control circuit activation, preventing electrical hazards during mating/unmating.Ideal for aviation maintenance, vehicle jump-starting via slave cables, and tactical operations, this socket offers superior durability with silver-plated contacts for low resistance and high conductivity. Constructed from impact-resistant polycarbonate housing (typically red for easy identification), it withstands extreme conditions including vibration, shock, and temperature fluctuations. Panel-mountable with threaded flange for secure installation on bulkheads or chassis.This connector supports up to 500A peak current (with appropriate cabling) and is widely used in small general aviation aircraft, helicopters, and NATO-compatible military systems. Variants available for custom wiring or environmental sealing. Bulk orders welcome for exporters and OEMs.
Rated Voltage	1100 Volt (V)
Weight	1.6 KG
Color	Black
Phase	3 Phase
Frequency	400 Hertz (HZ)
Rated Current	500 Ampere (amp)
Conductor	Copper
Material	Rubber
Payment Terms	Cash Advance (CA), Cash in Advance (CID)
Supply Ability	50 Per Week
Delivery Time	10 Days
Sample Available	Yes
Sample Policy	If order is confirmed we will reimburse the sample cost
Main Export Market(s)	Asia, Asia
Main Domestic Market	All India
