Cs209a Metal Proximity Detector Ic

Cs209a Metal Proximity Detector Ic

Get Latest Price

Brand Name :

Dha

In Stock

In Stock

Product Specifications

Dimensions3mm x 3mm
FeaturesMetal Detection, Proximity Sensing, High Sensitivity, Low Power, Stable Operation, Compact Size, Easy Integration
MaterialBipolar Monolithic IC
Operating Temperature0-70°C
Oscillator FrequencyVariable
Output Current20mA
Package TypeSOIC-8
Supply Voltage12V

Product Overview

Key Features

The LD209A (analog CS209A) is a bipolar monolithic integrated circuit for use in metal detection/proximity sensing applications.
The IC (see block diagram) contains two on-chip current regulators, oscillator and low-level feedback circuitry, peak detection/demodulation circuit, a comparator and two complementary output stages.
The oscillator, along with an external LC network, provides controlled oscillations where amplitude is highly dependent on the Q of the LC tank. During low Q conditions, a variable low-level feedback circuit provides drive to maintain oscillation. The peak demodulator senses the negative portion of the oscillator envelop and provides a demodulated waveform as input to the comparator. The comparator sets the states of the complementary outputs by comparing the input from the demodulator to an internal reference. External loads are required for the output pins.
A transient suppression circuit is included to absorb negative transients at the tank circuit terminal.
