Copper Armoured Cable

Price:

Get Latest Price

Minimum Order Quantity :

In Stock

Product Specifications

Usage & Applications	Suitable for underground installation, industrial, commercial, heavy-duty outdoor use
Weight	Varies as per length and cross section
Core Material	Copper
Number of Conductor	Single core, Two core, Three core, Four core or customized
Tensile Strength	12.5 N/mm2 (conductor), armor provides additional mechanical strength
Install Type	Direct burial, cable trays, ducts, trenches
Conductor Shape	Other, Circular/Segmental
Operating Temperature	-15C to +90C
Insulation	XLPE/PVC
Cable Type	Low Voltage Armoured Cable
Diameter	Varies per core size, typically 10-50mm
Impedance	Depends on cross-sectional area and construction (typically 0.01 - 0.2 ohm/km)
Core Number	1, 2, 3, 4 (as per requirement)
Dielectiric Strength	Above 3.5 kV/5 minutes (typical)
Conductor Type	Other, Stranded or solid (as per specification)
Armored Material	Steel wire or steel tape
Rated Temperature	-15C to +90C
Features	High mechanical protection, Flame retardant, Weatherproof, UV resistant
Product Type	Copper Armoured Cable
Length	Available in customized length or standard coils (100m, 500m, 1000m)
Voltage	Other, 600/1000V
Insulation Material	Other, PVC/XLPE (Cross Linked Polyethylene)
Application	Other, Power transmission & distribution, industrial wiring, building wiring
Conductor Material	Other, High conductivity annealed copper
Jacket Material	Other, PVC or HDPE (Polyvinyl Chloride/High-density Polyethylene)
Storage Temperature	-20C to +70C
Connector Color	Copper (no separate color at core ends by default)
Shield Material	Steel Wire Armour (SWA) or Galvanized Steel
Jacket Color	Black
Dimension (LWH)	Varies as per size, typically cable diameter is 10mm - 50mm
Color	Black outer sheath, cores color coded as per standards
Material	Copper conductor, steel armor, PVC/XLPE insulation and jacket
Size	1.5 sq.mm to 400 sq.mm (cross-sectional area)
Payment Terms	Cash in Advance (CID)
Supply Ability	5000 Per Month
Delivery Time	2-5 Days
Main Domestic Market	All India
