Continuous Multi Layer Mesh Belt Dryer - Capacity: 5000 Kg/hr
Price: 23710 INR / Set
Get Latest Price
Minimum Order Quantity :
1 Set
In Stock
Product Specifications
| Heating Method | Electricity,coal, natural gas, diesel oil,wood, biomass particles |
| Features | Automatic continuous drying process |
| Machine Type | industrial bamboo shoot mushroom dryer |
| Usage | Industrial |
| Material | Steel |
| General Use | food,vegetables,fruits,fish,onion,cassava,mango,pasta,tomato,etc. |
| Size | Standard |
| Type | Food Dryer |
| Product Type | Continuous Multi Layer Mesh Belt Dryer |
| Capacity | 5000 Kg/hr |
| Weight (kg) | 2000 Kilograms (kg) |
| Product Shape | Other |
| Computerized | Yes |
| Automatic | Yes |
| Control System | PLC Control |
| Voltage | 220-420/customized Volt (v) |
| Power | 30-95kw Watt (w) |
| Dimension (L*W*H) | 10000*2000*2600 Millimeter (mm) |
| Feature | ECO Friendly, Low Noice, Lower Energy Consumption, Compact Structure, High Efficiency |
| Color | Other |
| Warranty | 1 year |
| Payment Terms | Telegraphic Transfer (T/T), Others, Letter of Credit (L/C), Paypal |
| Supply Ability | 20 Per Month |
| Delivery Time | 10 Days |
| Sample Available | No |
| Sample Policy | Contact us for information regarding our sample policy |
| Packaging Details | container |
| Main Export Market(s) | South America, Asia, Australia, Central America, North America, Eastern Europe, Western Europe, Middle East, Africa |
| Main Domestic Market | All India |
| Certifications | CE,ISO,CCC |
Product Overview
Key Features
Continuous mesh belt conveyor onion dryer drying machine,grated cassava dryer,crayfish drying machines, vegetables, fruits and other raw materials are conveyed from the first layer to the last layer by a conveyor belt and the dried vegetables and fruits are conveyed by a discharge conveyor. The belt vegetable and fruit dryer uses hot air as the drying medium. The hot air passes through the material from the bottom to the top. The final moisture comes out of the top of the belt vegetable fruit dryer. The dryer can not only use heat for drying, but also use strong air for drying. Therefore, it can improve drying efficiency and shorten drying time. It is more convenient and no require manual loading and discharging.
Heated air dryer washer blanched dehidrator machine chicken meat coffee ground grated cassava crayfish sausage drying machine | |||||
Model(Width*Length) | KT1.5-6-4 | KT2-8-4 | KT2-9-4 | KT2-10-4 | KT2-12-4 |
Layers | 4 | ||||
Drying area() | 29 | 45 | 51 | 57 | 69 |
Spread thickness of material(mm) | 50-200 | ||||
Working temperature() | 0-120 | ||||
Working time(hour) | 24 | ||||
Capacity(t/h) | 100-150kg/h | 200kg/h | 250kg/h | 300kg/h | 500kg/h |
heat exchange furnace(M) | 3.2*1*2.7 | 3.9*1.26*3 | 3.9*1.26*3 | 4.7*1.5*3 | 4.7*1.5*3 |
Induced draft fan(kw) | 11 | 15 | 15 | 22 | 22 |
Exhaust fan(kw) | 1.5 | 2.2 | |||
Feeding conveyor(kw) | 1.5 | 2.2 | 2.2 | 2.2 | 3 |
Discharge conveyor(kw) | 0.55 | ||||
Total power(kw) | 14.55 | 19.25 | 19.95 | 26.95 | 27.75 |
LP gas consumption (90 degree fanrenheit) | 20m/H | 25m/H | 28m/H | 30m/H | 36m/h |
Place requirement (W*L*H)M | 4.5*14*2.7 | 5*19*2.8 | 4.5*20*2.8 | 5.5*21*2.8 | 5.5*23*2.8 |
Our service
FAQ
Always a pre-production sample before mass production; Always final Inspection before shipment;
Normally 12 months. Except for wearing parts.
4.your delivery time?
We will arrange for shipping in factory within 15 working days after receiving the advance payment.
Company Details
KUNTENG company was founded in 1999. We have been engaged in manufacturing all kinds of industrial dryer machines, mesh belt dryers, heat pump dryers, brush roller washing machines, Air bubble washing machines, vegetable and fruit slicers, and food processing machines for many years. We got more patented technologies and honor. Our machine has passed ISO9001:2000CCC and CE certification. We provide customers with a one-stop service of design solutions, complete equipment, on-site installation, and after-sales support. Welcome to cooperation.
