Automatic Computerized Pattern Sewing Machine - 300x200mm Sewing Area, High-speed 2800 Rpm, Electric Operation, Grey Color | Versatile Stitching Options, User-friendly Interface, Precision Stitch Quality

This is a state-of-the-art sewing machine designed to streamline and automate the production of intricate patterns and designs. With its advanced computerized technology, this machine offers precise stitching and high-speed operation, making it an ideal choice for various industries such as apparel, automotive, upholstery, and home textiles.

Computerized Operation: The machine is equipped with advanced computerized technology that allows for precise and automated stitching of complex patterns. Users can create and input custom designs through the machine's user-friendly interface, eliminating the need for manual pattern marking and reducing production time.
Large Sewing Area: With a spacious sewing area of 300*200mm, this machine offers ample space to sew large-scale patterns and designs. The generous sewing area enables the creation of intricate and detailed designs on a wide range of fabrics and materials.
High-Speed Performance: The Automatic Computerized Pattern Sewing Machine is capable of high-speed stitching, significantly increasing productivity and efficiency. The machine's precise motor control and optimized thread tension system ensure consistent stitch quality, even at high sewing speeds.
Versatile Stitching Options: This machine offers a wide range of stitching options, including straight stitching, zigzag stitching, decorative stitching, and more. With the ability to customize stitch length, width, and density, users can achieve a variety of design effects and meet diverse application requirements.

Modelbs-2010bs-3020bs-6040
Sewing typesingle needle lockstitch
Max sewing speed2,800 rpm2,800 rpm2,800 rpm
Stitching area200x100 mm300x200 mm600x400 mm
Cloth feeding deviceintermittent feeding (driven by pulse motor)
Needle gauge0.05 -12.7mm
Can be saved by code50000 stitches/ sewing pattern
Highest sewing stitched for each pattern20000(a pattern)
Storagesd card built-in memory:2gb, 900 kinds
Clamp drivepneumatic
Clamp heightmax 35 mm
Clamp lowestone-piece pressure foot
Pressure foot lift up22 mm
Intermittent pressure foot0.2-4.5 mm or 4.5 mm (factory settings:3 mm)
Shuttle (hook)double hook(standard)
Thread wiper devicestandard equipment
Trimmer devicestandard equipment
Date memoryflash memory(can save with sd card) 3 inch disk 2hd/1.44bm.2dd,usb interface
No. Of user programs50
Loop program number9
Motorservo motor 750w
Weighthead: 160 kg, operating panel: 0.6 kg, control box: 16.2 kg
Powersingle phase 220v 3-phase 200v/380v/400v 500va
Air pressure0.5 mpa 1.81/min
