Compost Turner - Stainless Steel Construction, 700 Ton/hour Capacity | Energy Efficient Design, Quality Soil Amendment Production, Low Maintenance

From:

• Food Industry Waste

• Sugar Industry Pressmud

• Yard Trimming

• Agricultural Waste

• Municipal Organic Grabage

• Studge

• Horticulture Stable Waste

• Distillery Spent Wash (with Pressmud)

Salient Features:

• Produce a Quality Soil Amendment

• Most Economic Solution to prepare Bio-Fertilizer

• Uniform spraying of spent wash (effluent)

• Unique Design to save Energy Consumption

• Meet your Recycling Goats

• Easily Transported From Site to Site

• Sturdy Frame Structure

• Low Maintenance Cost

To keep the fertile value of agricultural land and for better productivity, Good Quality Bio-compost is needed. To get good quality Bio-compost in industrial scale, All the process parameters of Bio-compost manufacturing are to be maintain in correct order.

These Parameters are:-

• PH

• Temperatures

• Bacterial growths

• Moisture level

• Aeration Maturation

The first 1 to 4 parameters are maintain at desire level, But for faster Bio-degradation, Air is an essential element. Which can be given by mechanical equipment only.

In consideration of this need, We have developed mechanically operated Compost Turner (Aeration Machine) of following specification.

Technical Specification:

Frame Structure :

• Chasis 180x90x5 Thk. Rect. Section

• 4 Thk. M.S. Sheet

• Hood 90x90x5 Thk. Square Section

• 2.5 Thk. S.S. Sheet

Rotating Drum :

• 406 O.D. x 2794 L x 8 Thk. Seamless Pipe with specially designed &Hardened 84 No. blades, RPM-280

Spraying System:

• 1 S.S. 304 Nozzle, 12 Nos.

Spraying System :

• 5 H.P. Kirlosker Pump, Capacity 14 leter/sec.

Effluent Tank :

• 3900 Leter S.S. Tank with 02 Nos. spirit level gauge to indicate emply & Full tank.

Hydraulic System :

• 70x140x2210 O.C

Power Transmission :

• 02 Nos. Universal Joint with Seamless Square Section. Positive Driven

• Gear Box with Harden & Ground Bevel Gears

Tyre :

• 02 Nos. 9.00 x 20 (14 Ply)

• 01 Nos. 7.50 x 16 (16 Ply)

Windrow Size :

• Height : 1500

• Width : 2800

Capacity :

• 700 Ton/Hour

Input Power :

• 70 H.P. Tractor with 540 Power Take Off (P.T.O) Shaft RPM & Creeper
