Common Collector Amplifier - Application: Engineering Electronics Instruments
Price: 1200.0 INR / Piece
Get Latest Price
Minimum Order Quantity :
1 Piece
Brand Name :
Edutek
In Stock
Product Specifications
| Power Supply | External battery or DC adapter |
| Usage | ENGINEERING ELECTRONICS INSTRUMENTS |
| Operating Temperature | 0C to +50C (ambient) |
| Features | Easy demonstration, breadboard compatible, passive and active components |
| Components | Transistor (BC547/BC557), resistors, capacitors, connectors |
| Response Time | Fast; suitable for audio frequencies |
| Interface | Wire connectors / Pin headers |
| Output | Amplified analog signal (with unity voltage gain and high current capability) |
| IP Rating | Not rated |
| Thermal Conductivity | Standard PCB thermal properties |
| Input | Low-level analog signal (audio or test signal) |
| Power Source | DC Supply |
| Product Type | COMMON COLLECTOR AMPLIFIER |
| Application | ENGINEERING ELECTRONICS INSTRUMENTS |
| Rated Voltage | 9V DC |
| Supply Voltage | 9V DC |
| Size | Compact, approx. 8 cm x 5 cm |
| Dimension (L*W*H) | 8 cm x 5 cm x 2 cm |
| Function | Amplification of input signal in common collector configuration (emitter follower) |
| Color | Blue PCB with standard electronic components colors |
| Weight | Approx. 60 grams |
| Capacity | Single stage amplifier |
| Current Rating | 20 mA typical operating current |
| Thickness | Approx. 1.6 mm (PCB) |
| Frequency | Up to 100 kHz (depends on design and components) |
| Payment Terms | Cash on Delivery (COD), Cash Advance (CA), Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C) |
| Packaging Details | Carton Box, Export Quality also Available |
| Main Export Market(s) | Asia, Middle East, Africa |
| Main Domestic Market | All India |
| Certifications | ISO 9001, 14001, CE |
Product Overview
Key Features
COMMON COLLECTOR AMPLIFIER
Features:
Front panel built with high class insulated Printed Circuit Board sheet with well printed circuits and symbols.
Fuse for Short Circuit protection
Instruction manual.
Connections are brought out through 4mm Colored Sockets.
Patch Cords 4mm.
The trainer is housed in ABS Plastic cabinet.
Size of the trainer set 12x8
