Combo Base Horizontal Slip Table - Precision Granite Surface, Custom Square & Rectangular Size Options , Low-pressure Hydraulic Bearings For Enhanced Stability And Motion

Our combo base horizontal slip table eliminates the necessity for supporting test specimens by complicated flexures and permits simplified translational motion for testing the components in both horizontal axes x & y, without disturbing the orientation of tests objects. it is compactly constructed using a precision granite surface, internal oil reservoir, filter, regulator, a mg slip plate and the mg drive bar. They are available in both square and rectangular shape of custom size and can be used with all armatures. Stainless steel inserts are provided on the mg table in customer defined pattern. Driven by driver bar and t&v type low-pressure hydraulic/hydrostatic bearings, which controls crosstalk and high overturning moments, the slip table provides increased pitch, roll & yaw restraint even for tall and heavy loads. Slip table is constructed in a combo basea configuration to ensure perfect alignment when the shaker is rotated 90o for conducting the tests in horizontal axes. The magnesium table is easily movable along the horizontal axis in which the force is applied with minimum friction loss. Tarang also manufactures hydrostatic bearing slip table attachment when very heavy payloads with high cg as well as off centre loads have to be tested on your electrodynamic vibration shaker system.
