Yw Type Cnc Winding Machine - Stainless Steel, 800x1100x1300 Cm, 260 Mm Finished Core Od, 70 Tpm Winding Speed | High Precision, Automatic Tension Control, Low Noise Operation, User-friendly Touch Screen

We are Exporting, Manufacturing and Supplying a best collection of YW Type CNC Winding Machine in China, Nuevo Leon, Mexico for current transformer is the new generation of winding equipment according to the power industry requirement and present manual winding technology of current transformer.

Technical Parameters:

A. Max Winding Speed: 70TPM
A. Finished Core OD: 260 mm Max
A. Finished Core ID: 30 mm Min
A. Wire Gauge: 0.5~1.5mm
A. Used in producing CT Coils

Low Noisy
Complete Function
Wide Speed Range
Compact Structure
High Efficiency
High Winding Precision
Long Life Service
Simple And And Reliable System

Specifications:

1. Adopt most advanced PLC control system, touch screen easy control.
2. Tensioner adopts magnetic damper, solves the wire easy damage and dropping.
3. Short driving chain, large driving torque, wide speed adjustment range, low noise
4. Automatically wire loading, winding, change winding direction,
5. Dual-winding, multi-winding, forward winding, backward winding,
6. Large memory capacity.
7. High productive, human-computer interaction
8. Stepping motor ,tension control for smooth winding
9. User friendly control console with touch screen
10. Pitch can be programmed
11. Microprocessor based controls, easy for program-setting and handling for operator.
12. Large memory capacity for storing steps of winding.
13. Password protection for administrative settings as well as operators setting.
